Name: Automatic Transmission Oil Pump Seal &#8211; Cadillac DeVille 64-82, Eldorado 64-66, Fleetwood 65-84, Seville 76-79 6712NA
SKU: cfyqjfqh71473
Availability: InStock

Description

Automatic Transmission Oil Pump Seal – 6712NA

Common Applications Include:

Cadillac – DeVille 1964-1982, Eldorado 1964-1966, Fleetwood 1965-1984, Seville 1976-1979

Chevrolet – C10 1975-1986, C20 1975-1986, C1500 1988-1990, C2500 1988-1992, Camaro 1967-1981, Caprice 1966-1984, Chevelle 1964-1973, Corvette 1953-1981, El Camino 1959-1984, G10 1975-1990, G10 Van 1964-1974, G20 1975-1990, G20 Van 1967-1974, G30 1975-1990, G30 Van 1970-1974, K10 1975-1986, K10 Pickup 1960-1974, K10 Suburban 1967-1984, K1500 1988-1990, K20 1975-1986, K20 Panel 1967-1967, K20 Pickup 1960-1974, K20 Suburban 1967-1986, K2500 1988-1992, K30 1977-1986, K30 Pickup 1968-1974, K3500 1988-1990, K5 Blazer 1975-1986

GMC – C1500 1979-1990, K2500 1979-1990

Pontiac – Bonneville 1965-1984, Firebird 1967-1981

Product Specifications

Flanged Outside Diameter (in)	3.045
Flanged Outside Diameter (MM)	77.343
Helix Type	Clockwise-Spiral Lip Design
Housing Bore (IN)	2.758
Housing Bore (MM)	70.050
Inside Diameter (IN)	1.875
Inside Diameter (MM)	47.630
Material	Polyacrylate
Outside Diameter (IN)	2.762
Outside Diameter (MM)	70.150
Redicoat	Yes
Sealing Material	Polyacrylate
Shaft Diameter (IN)	1.875
Shaft Diameter (MM)	47.630
Thickness (IN)	0.425
Thickness (MM)	10.800
Type	75
Width (IN)	0.425
Width (MM)	10.800
