Name: Brake Drum Ford Mustang 1964-1972 Falcon 60-70, Comet 60-72 Rear 9 x 1 1/2 AX8147 BD8147
SKU: mlxhwkso11561
Availability: InStock

Description

Brake Drum – AX8147 Rear (Ford Mustang 1964-1972, Falcon 1960-1970, Mercury Comet 1960-1972)

9×1 1/2

Features & Benefits:

Castings engineered to exact metallurgical standards for consistent quality, strength and performance
Enhanced Ra braking surface finish supports brake shoe bedding
Premium Core Technology allows non-machined areas of the drums to be more detailed
Tested for balance on advanced balancing testing machines

Common Applications Include:

Product Specifications:

Abs Tone Ring Included	No
Bolt Circle Diameter (IN)	4.5
Bolt Circle Diameter (MM)	114.3
Bolt Hole Diameter (IN)	0.62
Bolt Hole Diameter (MM)	15.7
Bolt Hole Quantity	4
Brake Surface Width (IN)	1.84
Brake Surface Width (MM)	46.7
Center Hole Diameter (IN)	2.44
Center Hole Diameter (MM)	62
Construction	Composite
Material	Cast Iron / Steel Top
Maximum Brake Diameter (Discard) (IN)	9.09
Maximum Brake Diameter (Discard) (MM)	230.89
Nominal Drum Diameter (IN)	9
Nominal Drum Diameter (MM)	228.6
Outer Cooling Fins	No
Outside Diameter (IN)	10.75
Outside Diameter (MM)	273
Overall Height (IN)	2.36
Overall Height (MM)	60
Rust Resistant Coating	No
