Name: Edelbrock Performer High-Compression 454-O Cylinder Head &#8211; Chamber Size: 100cc
SKU: psfdyyxd22010
Availability: InStock

Description

Cylinder Head Specifications: Combustion chamber volume: 100cc; Intake runner volume: 290cc; Exhaust runner volume: 110cc; Intake valve diameter: 2.19\”; Exhaust valve diameter: 1.88\”; Valve stem diameter: 11/32\”; Valve guides: Manganese bronze; Deck thickness: 9/16\”; Valve spring diameter: 1.55\”; Valve spring maximum lift: .700\”; Rocker stud: 7/16\”; Guideplate: Hardened steel; Pushrod diameter: 3/8\”; Valve angle: 26 °; Exhaust port location: Stock; Spark plug fitment: 14mm x 3/4 reach, gasket seat. * Match with Edelbrock head gasket sets. Bare heads will have valve guides and seats installed, but will require final sizing & a valve job to match the valves you will be using. Recommended spark plugs 14mm x 3/4\” reach with flat gasket seat (Champion RC12YC).

Edelbrock, BBC, Big Block Chevy,454, 396, 402, V8, Cylinder Heads, 60499, Flat Tappet, TBI

Match with Edelbrock head gasket sets.

Recommended spark plugs 14mm x 3/4\” reach with flat gasket seat (Champion RC12YC).

100cc semi-open chamber cylinder heads feature a 1-1/2 Degree rolled over (angle milled) design that improves intake port alignment and provides a smaller combustion chamber without shrouding the valves

9.2:1 compression with flat-top pistons for an outstanding high Performance’s street head

8.8:1 compression ratio when used on 1987-95 TBI-equipped 7.4L dished piston engines

Performer applications include heat crossover passage for emissions related engines

Performer 454-O are 50-state street legal

Since 1938, Edelbrock has been committed to making the finest high performance products in the industry. The famous Edelbrock Intake Manifold, Edelbrock Aluminum Cylinder Heads and Edelbrock Water Pumps have become the industry standard. Edelbrock cylinder heads offer improved performance throughout the rpm range for great throttle response and top-end horsepower. Edelbrock Victor Jr. cylinder heads are ideal for racers looking for an affordable head that makes maximum power. They have a high horsepower potential out-of-the-box, for a cost effective, race-winning set-up. Edelbrock Victor Cylinder Heads and Edelbrock Victor CNC Cylinder Heads are used by many of the best racers in the country and are the best choice for all-out competition. An Edelbrock intake manifold will provide the power right where you want it.

Product Descripton:

Cylinder Head

Performer High-Compression

Assembled

2.190 / 1.880 in Valve

290 cc Intake

100 cc Chamber

1.550 in Springs

Aluminum

Big Block Chevy

Sold Individually
